General |
| Physical
dimensions (H x W x D) |
2.68" x
6.18" x 4.06" (68 x 156.9 x 103.2 mm) |
| Weight |
11.1 oz
(316 g) |
| Water
rating |
IPX6 and
IPX7 (front panel only, when properly installed) |
| Power input |
10.8-16 VDC |
| Operating
temperature range |
32° to 122°
F (0° to 50° C) |
| Current
(max.) |
15 A |
| BLUETOOTH
wireless range |
BLUETOOTH
wireless range |
| ANT
wireless range |
Up to 10 ft
(3 m) |
| Wireless
frequencies/protocols |
Bluetooth
2.4 GHz @ +12 dBm nominal |
|
Compass-safe distance |
5.9" (150
mm) |
|
Stereo Features |
| Display |
2.3"
perimeter bonded monochrome dot matrix LCD |
| Built-in
amplifier |
Class-D
(minimum 4 ohm impedance) |
| Peak power |
180 W |
| Rated power
output (4 ohm) |
22 W rms x
4 @ 14.4 V input, 4 ohm, 10% THD |
|
Fusion-Link™ control |
yes (with
compatible Apple and Android devices) |
| Fusion-Link
Lite control |
yes (with
compatible Garmin watch) |
| Multi-Zone™
technology |
2 zones |
| BLUETOOTH
wireless technology |
yes |
| ANT
wireless technology |
yes |
| DAB+ |
yes (DAB
tuner built in) |
|
Multi-language interface |
Dutch/English/French/German/Italian/Spanish |
| Software
updates |
Over-the-air software updates via BLUETOOTH wireless technology using the
Fusion-Link app |
| Warranty |
1 year |
|
Sources |
| Sources |
AM/FM/BLUETOOTH/AUX x1/DAB+ (available in Europe and Australia only) |
|
Connectivity |
| Auxiliary
input |
One RCA
input (AUX) |
| AM/FM radio |
One
Motorola antenna connector port |
| Speaker |
4 x speaker
connections (2 amplified zones) |
| 4 x speaker
connections (2 amplified zones) |
1 zone
(requires external amplification) |
| Line out |
Zone 1: L +
R (requires external amplification) |
| Subwoofer
out |
Zone 1
(requires external amplification) |
