Lumishore Eclipse DL55 Blue & White Down Light
12/24vDC Black Housing
Model: 010-04476-00
Lumishore’s ECLIPSE Downlights provide excellent illumination to enhance a
variety of indoor or outdoor overhead spaces onboard.
Constructed of a durable aluminium body with a glass front, completely water
sealed and IP67 rated.
Simple to install (2 wire hookup) with a shallow depth profile of only 21mm
(0.83").
Available in dual color blue and white, single color blue or white, and White +
RGB. Choose from a black or white finish to complement your boats aesthetic.
Specifications
| Colors |
Blue &
White (5000 K) |
| LED Type |
2 x 3W Blue
LEDs / 2 x 3W White LEDs |
| Customer
Control Options |
On/Off
Switch or ECLIPSE Command Center |
| Electrical
Installation |
Simple 2
Wire Installation |
| Supply
Voltage Range |
12V DC Only
(10 - 15V DC) |
| Max Current
Draw (12/24V DC) |
0.4A |
| Ingress
Protection |
IP67 |
| Front
Diamater (Bezel) |
64.0mm
(2.519") |
| Profile |
3.5mm
(0.137") |
| Hole
Diameter for fitting |
50.8mm
(2.0") |
| Mechanical
Installation |
Stainless
Steel Spring Clips |
| Warranty |
3 Years |
