Kick back, relax and let NavPilot steer you to your
destination
FURUNO’s NavPilot is a revolutionary autopilot with a sunlight viewable
display designed for a variety of vessels. It utilizes a self-learning and
adaptive software algorithm, and plays the ultimate role in course-keeping
capability. NavPilot dynamically adjusts essential parameters during navigation,
such as vessel speed, trim, draught, tide and wind effects, dead band, weather
and more. These parameters are stored in system memory and continuously
optimized to make the NavPilot more versatile.
The NavPilot 711C-S package includes a 1.0L pumpset for boats with
single-cylinder steering systems.
Powerful new tools enhance safety and comfort
The optional SAFE HELM and POWER ASSIST features provide a unique interface
to the vessel's hydraulic hand steering system, providing unrivaled comfort and
control of steering directly from any manual helm on the vessel. These two modes
greatly reduce steering effort and enhance the safety of your autopilot. The
POWER ASSIST mode incorporates the SAFE HELM concept and provides speed-based,
power assisted steering, which greatly reduces manual helm effort in maneuvering
situations. POWER ASSIST is a unique helm-activated assisted steering feature
that can augment or replace separate electric and power-robbing, engine-driven
power steering systems on many vessels. POWER ASSIST reduces steering system
complexity and costs while increasing economy.
SAFE HELM and POWER ASSIST modes will
require the optional FPS8 Power Steering Module and an appropriate HRP Pumpset.
In the Box:
- FAP7011C - Control Unit
- FAP7002 - Processor Unit for NAVpilot 700 Series
- FAP6112 - Rudder Reference Unit for NAVpilot
- PG700 - Fluxgate Magnetic Sensor With Enhanced Stability By A Solid-State Rate Gyroscope, w/ 6M Cable
- PUMPOCT1012 - 1,000CC/MIN OCTOPUS PUMP, 12V, 1.0 Cubic Inches per second (For Ram sizes from 7-12 Cubic Inches in volume)
Technical Info
Interfacing and Installation
