Marine Product Guides > Marine GPS Guides >

Raymarine GPS Guide




Ethernet



An address based data packet network capable of high speeds (10/100/1,000Mbs) originally developed for the computer industry that is seeing adoption in the marine industry. Ethernet networks are designed as a star topology. Systems of three or more nodes require a hub, router or switch to facilitate all point to point connections. An NMEA standard for the transfer of NMEA 2000 messages using an Ethernet protocol is being developed that will be called OneNet.



Cable System

There are numerous cabling systems for Ethernet but the ones applicable to Raymarine installations include:





 RJ45    SeaTalk hs    RayNet

 Wifi

Cat5 w/ RJ45   SeaTalkHS   RayNet   WiFi
The standard cable/connector of the computer industry that is very low cost but alternatives such as SeaTalkHS and RayNet are preferred connectors in the marine environment.

Raymarine’s first generation Ethernet connector which consisted of putting a waterproof collar around an RJ45 connector.



Explore SeaTalkHS

  Raymarine’s current generation system that replaces the RJ45 connector with a waterproof vibration tolerant twist pin connector that is designed for the marine environment.   A wireless system that doesn’t use any wires that provides for low cost flexible installations but are not as robust as wired systems. WiFi is ideal for non-mission critical accessory connections.







Available cables:



RayNet to RayNet Cables



The new RayNet (F) to RayNet (F) network cable can be used to daisy-chain 2 adjacent RayNet devices together. It is also useful for joining two adjacent HS-5 Network Switches together on larger systems where multiple switches are necessary. This network cable is 15-inches (400mm) long.


This cable joins our existing line of RayNet interconnect cables available in 400mm, 2, 5, 10 or 20 metre lengths.




Product

Product Compatibility Data Length
Part Number


Cable

RayNet to RayNet Port Connectivity Ethernet

400mm

A80161
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

2m

A62361
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

5m

A80005
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

10m

A62362
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

20m

A80006
 RayNet to RayNet



NMEA 2000 / SeaTalkng



The current marine industry standard. All current Raymarine MFDs are NMEA2000 certified. The standard utilises the CAN (Control Area Network) design developed by Bosch for the automotive market but with messages/sentence appropriate for the marine industry.



A multi-talker, multi-listener approach using serial data at moderate date rates (250kbs).



Cable System



Under the NMEA standard, manufacturers can use the cable/connector design of their choice so long as it conforms to certain requirements. The topology is a robust terminated backbone/spur design.





 SeaTalk ng    SeaTalkng

Raymarine’s proprietary cable system for use in NMEA 2000 networks. The design provides two advantages. First, the connector collars are retained on the product which allows for a smaller cable diameter making installations easier. More importantly, the cable can include a sixth wire which allows for backward compatibility with SeaTalk1 equipment. Products with SeaTalkng connectors can be used on NMEA 2000 networks that use Devicenet cabling through simple connector adaptors and conversely equipment with Devicenet connectors can be used on NMEA 2000 networks that use SeaTalkng cabling through simple connector adaptors.



Explore the networking possibilities with SeaTalkng


DeviceNet    Devicenet

Created for the factory automation industry, Devicenet has been approved by the NMEA for NMEA 2000 installations.



Explore Devicenet cables





Available cables:



Backbone Cables



In a SeaTalkng installation, a backbone cable runs through the length of the boat.



Individual devices connect to the backbone by spur cables that run to T-pieces on the backbone. The backbone carries both data and power to attached devices. The backbone should be sized so that it will run past every location where an NG or NMEA 2000 device might be installed.



Two backbone cable lengths can be joined together by part A06030, a backbone extender.





Backbone Cable

Backbone cable
Available in a number of different cable lengths







Cable length Part number
15.7in (400mm) A06033
3.25 ft (1m) A06034
9.75ft (3m) A06035
16.25ft (5m) A06036
29.25ft (9m) A06068
65ft (20m) A06037



SeaTalk / SeaTalk1



SeaTalk / SeaTalk1

Raymarine’s proprietary network design released at the same time as NMEA0183 that had several key advantages. SeaTalk1 is included in many Raymarine MFDs and instruments to provide legacy support but now NMEA 2000 offers several advantages over SeaTalk1.



Data

A multi-talker, multi-listener approach using serial data at low data rates (4.8Kbps).



Cable System

The network used proprietary cables and connectors that were designed for the marine environment. The connectors are three pin moulded and incorporate 1/8” automotive spades as mating elements. The network could be implemented as either a simple daisy chain structure or the more robust approaches of backbone/spur or star design.



Cables available for:



Multifunction Display Seatalk1 Cables



Product

Product Compatibility Data Length
Part Number


Cable (Straight)

E-Wide

C-Wide

Power/Seatalk1/NMEA0183/Video 1.5m
R62131
R62131

Cable (Right Angle)

E-Wide

C-Wide

Power/Seatalk1/NMEA0183/Video 1.5m
R62227
R62227

Cable

G-Series

E-Classic

Seatalk1/Alarm out 1.5m
E55054
E55054



NMEA 0183



NMEA 0183

The first industry standard marine network specification released over 20 years ago. While still frequently used by VHF radios, most other applications have migrated to NMEA 2000.



Data

A single-talker, multi-listener approach using serial data at low data rates (initially 4.8Kbps now up to 38Kbps). Message formats are standardised to provide cross-vendor interoperability.



Cable System

Uses a daisy chain architecture but there is no standard for cables or connectors. The daisy chain design is low cost and simple but it is susceptible to having a single point of failure taking down the network. Most implementations of NMEA 0183 use terminal block connections which are simple to install but failure prone in a marine environment.



View NMEA 0183 cables for:



Multifunction Display NMEA0183 Cables



Product

Product Compatibility Data Length
Part Number


Cable (Straight)

E-Wide

C-Wide

Power/NMEA0183 1.5m
R62131
R62131

Cable (Right Angle)

E-Wide

C-Wide

Power/NMEA0183 1.5m
R62227
R62227

Cable

G-Series

E-Classic

C-Classic

Power/NMEA0183 1.5m
R08004
R08004

Cable

A50

A57

A70

 Power/NMEA0183 2m
R62157
R62157

Cable (Straight)

e7/e9/e12/e16

c9/c12

Power/NMEA0183/Video 1.5m
R62379
R62379
Cable (Right Angle) e7/e9/e12/e16

c9/c12

Power/NMEA0183/Video 1.5m
R70029
R70029



Raymarine SeaTalkhs Connections

SeaTalkHS diagram with HS5

SeaTalkhs Plug and Play



By using SeaTalkhs networking, you can instantly transfer radar, chartplotter, fishfinder, thermal imaging and navigation functions. Configuring your system is a simple as determining which SeaTalkhs devices you'd like to have (chart, radar, sonar, video) and where you would like to see them.



space



Networking two devices



The most basic system may consist of a C Series Widescreen or an E Series Widescreen with a DSM30, DSM300 or a radar.



Using a SeaTalkhs Crossover coupler, they can be quickly and easily connected together. Because the components are all auto sensing, there is no complicated setup required. Simply plug them in.



If you're not using a DSM, you can link any two E Series Widescreen displays with the crossover coupler too.

 Sea Talk HS with coupler and E Series Wide





space





HS-5 SeaTalk HS Network Switch

Multistation Networking - New HS-5 SeaTalkhs Network Switch



SeaTalkhs data is quickly distributed to other SeaTalkhs using the HS-5 Network Switch.



The switch has 5 ports - 4 RayNet ports supporting 10 or 100 Mbit/sec network speeds and a 5th gigabit port allowing a higher speed across switches, should a 2nd switch be necessary.









When networking three to eight SeaTalkhs devices, the SeaTalkhs Network Switch can be used.





The auto sensing SeaTalkhs components make setup a breeze, simply plug them in. SeaTalkhs does the rest.

SeaTalk HS Network Switch





space



SeaTalkhs Raymarine Products



The following devices have SeaTalkhs connections and can be easily connected together via the SeaTalkhs network switch and SeaTalkhs network cables:





E Series SeaTalk HS network





space





 SeaTalk HS Cable

SeaTalkhs Network Cables



Available in multiple lengths to simplify installation, the SeaTalkhs network cable locks positively into switches and couplers.





Sizes Available Product Number
1.5m E55049
5m E55050
10m E55051
15m A62135
20m E55052













space





SeaTalkhs Patch Cables



Highspeed patch cable for connecting a SeaTalkhs switch with a PC or G Series monitor.





Sizes Available Product Number
1.5m E06054
5m E06055
10m E06056



Patch cables





space





 Dual End Waterproof

SeaTalkhs Dual End (Waterproof) Cables



The Raymarine SeaTalkhs Dual End Weatherproof Network Cable is designed to connect your Raymarine C-Wide or Raymarine E-Wide to a DSM30 or DSM300.





Sizes Available Product Number
1.5m A62245
15m A62246











RayNet to RayNet Cables



The new RayNet (F) to RayNet (F) network cable can be used to daisy-chain 2 adjacent RayNet devices together. It is also useful for joining two adjacent HS-5 Network Switches together on larger systems where multiple switches are necessary. This network cable is 15-inches (400mm) long.


This cable joins our existing line of RayNet interconnect cables available in 400mm, 2, 5, 10 or 20 metre lengths.




Product

Product Compatibility Data Length
Part Number


Cable

RayNet to RayNet Port Connectivity Ethernet

400mm

A80161
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

2m

A62361
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

5m

A80005
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

10m

A62362
 RayNet to RayNet

Cable



RayNet to RayNet Port Connectivity



Ethernet

20m

A80006
 RayNet to RayNet



Raymarine SeaTalkng Connections



Interconnection Bus for Raymarine Products



SeaTalkng is an interconnection bus for Raymarine products. Small diameter cable connectors are used throughout the system to make installation easier.



There's a wide range of cable lengths, all with over-moulded plugs, so there is no need to cut or splice cables. Spur cables connect individual SeaTalkng products to the SeaTalkng backbone.



 SeaTalk ng Networking diagram



 Click here to see the above diagram in more detail



Whether you are looking to expand your current SeaTalkng system, update your electronics suite or completely refit, it couldn’t be easier with SeaTalkng.





space



Color-coded cables



Cables and connectors are color-coded for easy system identification and have quick-connect (push-fit, twist-lock) waterproof (IPx6) plugs and sockets.



  • Backbone cables, plugs, sockets and terminators are coded blue.
  • Spur cables, plugs, and sockets are coded white.
  • SeaTalk to SeaTalkng converter cables, plugs and sockets are coded yellow.
  • SeaTalkng power cables are coded red.



View the cables and components in more detail



space



iTC-5





Connectivity



Transducer signals are easily converted to SeaTalkng with the iTC-5 component.



Discover more about the iTC-5















space



Converting Sea Talk1 to SeaTalkng



Specific Raymarine products (e.g. ST70 instruments) perform a bridging function, to enable you to connect SeaTalkng to SeaTalk1 products via appropriate adaptor cables.



Discover more about the SeaTalkng to SeaTalk1 converter kit



Adaptor cables are also available to connect NMEA2000 products.

ST1 to STNG(1)





space



Hardware



SeaTalkng comprises a single backbone terminated with two terminators, one at each end. Spur cables connect the backbone to individual SeaTalkng products.



Small diameter cable connectors are used throughout the system to make installations easier. Cables and connectors are color-coded to reduce the likelihood of misconnection.





Typical SeaTalk NG network  The SeaTalkng Backbone kit contains everything you need to construct and wire a basic SeaTalkng navigation network backbone on board your vessel.  The kit contains the following components:
  • A06031 SeaTalkng Terminators (Qty. 2)
  • A06037 Backbone Cable, 65.62ft (20m)
  • A06036 Backbone Cable, 16.4ft (5m) (Qty. 2)
  • A06028 T-Piece (Qty. 4)
  • A06049 Network Power Cable
  • 81300 SeaTalkng Reference Manual





Note: ST70 Displays, transducer pods, transducers and network spurs are not included.



Introducing the completely redesigned LightHouse II













PREVIEW


















Clear and simple design....



The high-contrast colour and bold new design of LightHouse II gives clear readability and ease-of-use in all lighting conditions.



gS Series and aSeries




LightHouse Chart Menu

Smarter, sharper and more powerful...



Re-designed for clarity and simplicity, LightHouse II's fluid touchscreen experience makes accessing navigation information as simple as using a smartphone.



New menus make navigating to your favourite features quicker than ever, while toggle keys clearly indicate which features are enabled or disabled. Customise the menu with dark or light menu palette options.



LightHouse II also features a new DataBar Auto-Hide feature for maximum on-screen viewing.








Over 20 New Features, Including....





 Sonar Support



Waypoint Icons



Sonar Charts

Multiple Sonar Support



Expanded Waypoint Symbols and Colours



Support for Navionics Sonar Charts



GPX Waypoint



Databar on Radar Screen



Pinch to zoom

GPX Waypoint Transfer



DataBar Auto-hide



aSeries pinch to zoom






Waypoints and routes are simple...



LightHouse II has all-new waypoint sorting and searching options; making it easy to find, retrieve, and navigate to all your saved hotspots and destinations.



LightHouse II supports up to 200 waypoints per route and uses the popular GPX file format for simple transfer.

   Waypoint Management



Introducing LightHouse Charts for US Waters....



The redesigned LightHouse II enables support for Raymarine’s new LightHouse Vector and Raster Charts. Derived from freely available NOAA charts, LightHouse Charts are the simple solution for navigating U.S. coastal waters.



Raster Nautical Charts

Raymarine Raster Charts



 e12 with LightHouse Charts



 Vector Charts



Raymarine Vector Charts



The LightHouse II chart engine is engineered for the future, allowing Raymarine to offer new LightHouse chart types and regions from around the globe.

LightHouse II also supports industry-leading Navionics vector charts including Navionics new community-sourced Sonar charts.





Important Radar Information



Radar with Multifunction Display

Safe Emissions



Powerful enough to slice through atmospheric clutter, Raymarine radars still comfortably meet international limits for energy absorption - in fact, the energy absorbed from an ordinary mobile phone can be several times greater than that from a correctly installed Raymarine radar.







Installation



All radars work on line-of-sight principles so although antennas could theoretically be fitted almost anywhere, unobstructed and parallel to the water line is better.



Radome Radar on Buster







Radar screen with mfd



Interference Resistance



Raymarine's radars use interference rejection technology to resist signal interference from other vessels' transmissions as well as close proximity objects already fitted to the boat.





Pulsed magnetron vs broadband (FMCW) radar technology



Broadband (FMC) radars typically emit low levels of energy, resulting in loss of ultimate performance in conditions of fog, rain, spray and snow, and limiting target detection at longer ranges.



Raymarine pulsed magnetron radars combine low average energy with high peak powers allowing the radar to detect targets at greater ranges, and to punch through adverse weather conditions ensuring targets are identified.



Raymarine HD Digital radar image













RACON



RACON and SART



Raymarine radar antennas also trigger RACON beacons and home in on signals from Search And Rescue Transponders.



Digital, HD Color, Super HD Color Radar



Raymarine Marine Radar



Raymarine radar - What's the difference?





Raymarine Digital radar image

Digital radar



Offers 4kW capability for improved performance and uses digital processing for increased target definition. Digital reduces the cable size (compared to analog) and makes an easier interface to larger systems. Lower power consumption and costs less than a full HD Digital system.



Available models: Digital Radome











HD Color radar



Raymarine's HD Color radar utlizes powerful signal processing technologies that help: distinguish between target types, automatically detect weak and distant contacts, and virtually eliminate clutter and noise. The truly adaptive transmitter and receiver automatically adjusts to changing environmental and sea conditions. HD Color radar delivers a dramatically clearer radar picture with crisp, well-defined contact echoes and a life-like target presentation.



Available models: HD Color Radome and HD Color Open Array



Raymarine HD Digital radar image







Super HD Radar screen



Super HD Color radar



Super HD Color radar is a giant leap forward in marine radar. Using highly advanced digital signal processing, Super HD Color radar has much greater dynamic range than conventional radar enabling the digital receiver to acquire and process vast amounts of echo information that is normally lost by conventional analog radar systems. Super HD Color technology intelligently isolates and identifies true radar targets, while simultaneously eliminating unwanted clutter. The extra-narrow beam width, pinpoints targets with stunning clarity. The result is a dramatically clearer radar display.



Available models: Super HD Color Open Array





Image Comparison



Digital vs HD Color



HD Color vs Super HD Color



Features Digital vs HD Digital Radar





Features HD Digital vs Super HD Digital Radar



HD Color targets are clearly defined compared to the standard Digital image.



  Super HD Color reveals even more detail than HD Color. The Super HD Color image shows that there are actually two targets in the ringed area, whereas the same targets on the HD image appear as one.



Raymarine Marine Radar Features



 Raymarine radar chart display





Chart view with corresponding radar overlay  Radar display





Raymarine radar delivers unmatched performance and ease-of-use



Raymarine's HD Color technology brings radar users the power of digital signal processing with a truly adaptive transmitter and receiver that automatically adjusts to changing environmental and sea conditions.







Raymarine weather advantage

Weather advantage



Raymarine's HD Color scanners provide superior all weather performance allowing you to still see targets through rain and thunderstorms. Use radar to track weather too.



During this abnormally heavy rain storm (see left hand image), rain mode was used to cut the clutter to clearly reveal the targets (see right hand image).





Cut the clutter



Detect targets at very close proximity to your vessel, or at very long ranges to see distant vessels, land features and even weather fronts. Distinguish targets through even the heaviest rain clutter.



Use the radar to see the weather coming, then use the radar overlay to map the weather pattern onto the chart.

  Raymarine weather advantage









Track Targets



Not everything transmits AIS!



Using MARPA* (mini-automatic radar plotting aid) allows you to identify vessel, speed, bearing, closest point of approach (CPA) and time to closest point of approach (TCPA), dangerous/proximity alarms, overlay AIS info for further target clarification.



*For the best radar overlay and MARPA performance fit a smart heading sensor or an SPX autopilot course computer.







Track Targets 1    Target (1) has been aquired (red circle overlay) using MARPA and is being tracked by your radar. Speed and bearing of the target are shown and the target's heading is shown as a thin red line at 65ş (2).







Track Targets 2    The tracked target has now moved into the previously set guard zone around your vessel and has triggered the dangerous target alarm, seen on screen, and set off an audible alarm







Radome or Open Array Radar Antenna?



When building a Raymarine Radar System you have your choice of either Open Array or Closed Radome scanner. Both Radomes and Open Arrays are fully compatible with every multifunction display and deliver unparalleled performance.




Raymarine Radome
Raymarine Open Array Antenna



Radar Type

Compatible with NEW e Series Multifunction Displays

NEW c Series Multifunction Displays

NEW a Series Multifunction Displays
C Series Wide Multifunction Displays

E Series Wide Multifunction Displays

G Series Multifunction Navigation

NEW e Series Multifunction Displays

NEW c Series Multifunction Displays

NEW a Series Multifunction Displays
C Series Wide Multifunction Displays

E Series Wide Multifunction Displays

G Series Multifunction Navigation

Models 4 kW,

18in or 24 in (45cm or 61 cm) models

4 kW and 12 kW

4 or 6 ft (1.2 or 1.8 m) models

Perfect for Sailboats

RIBs

Smaller Powerboats

Powerboats 40 ft and longer
Benefit Light weight and compact Narrow horizontal beam widths for enhanced target separation
Power Minimal power consumption Increased power output for improved long range performance
Additional Information Fewer Mounting Restrictions

No exposed moving parts to snag sails, rigging or lines
Longer range scales, up to 72 miles



Available Super HD Color systems for ultimate  clarity and target detection

Performance
  • Lower receiver noise figure (less than 5 dB) for more efficient target echo reception compared to competitive models
  • Auto GST™ Fully automatic Gain, Sea Clutter and Tune Control for hands off operation and optimum performance
  • Advanced microprocessor controlled transmitter receiver features eight Pulse width/PRF settings, providing enhanced targets returns though every range scale
Track targets3     The alarm has been acknowledged and the target's (1) (now overlaid with a red triangle to note possible danger) closest point of approach (CPA) to your vessel is shown on screen as 0.376nm (3) and time to closest point of approach (TCPA) is 4 mins 20 secs (2).

NEW! Raymarine a Series Touchscreen Multifunction Displays







a Series features



a Series specs







Preview brochure








Learn about LightHouse



Download Preview Brochure





a65 and a67 5.7" Multifunction Displays



Powerful, go anywhere, touch screen navigation displays, the a65 and a67 MFDs bring the speed and simplicity of Raymarine multifunction navigation into a sleek 5.7" display.



The a65 is the perfect choice for chartplotting and networking, while the ClearPulse® digital sonar equipped a67 is the choice of serious anglers looking for a powerful GPS/Sonar combo with extensive add-on options.



View the features





Raymarine c Series Multifunction Displays



A smart new shape for marine displays



New c Series displays are available in 9.0" (c95/c97) or 12.1" (c125/c127) widescreen LCD formats with LED backlighting that is both super bright yet energy efficient – uses up to 40% less than previous generation multifunction displays! Superior thermal management properties prevent darkening or screen blackouts at high temperatures. The bonded LCD screen eliminates condensation or contamination on the inside of the display, and maximises color and contrast by preventing unwanted reflections.



c Series features



c Series specs



c Series Networking

  LightHouse   RayView app

Explore Features



View the Specifications



Networking Options



LightHouse User Interface



Download the Free App

Discover the power of the new Raymarine c Series.



Compare the models and see the specifications.



See how the c Series networks with other Raymarine products.

  Watch the videos demonstrating the new LightHouse interface

Stream the c Series to your iPhone or iPad with the RayView app





Raymarine e Series HybridTouchTM Displays







Explore the features



View the specifications



e Series Networking

          RayView app










Networking Options









  Ordering Information














New look



The new e Series display's helm-friendly industrial design breaks away from box-like marine electronics and offers a clean, unobtrusive display solution that looks great on any helm. A smart new shape for marine displays, the sleek, low-profile, bezel offers maximum display size with minimum footprint. The rugged and handsome design is complemented by flush, easy-press buttons and "hidden" memory card slots along the right hand side.

What's new for e-Series?



  • LightHouse Version 4 Software for e Series and c Series displays now available. Download here



  • e7D display selected as the 2012 Editor's Choice award by Practical Sailor Magazine.

e165





Raymarine A Series Multifunction Displays



Powerful Chartplotting



Harness the power of Raymarine's advanced engineering and exclusive technologies with the A Series displays. Navigate like a pro using high resolution 2D or 3D and aerial photo charts and target fish with unprecedented clarity using Raymarine's unmatched HD Digital sonar technology.



HD DigitalTM Fishfinder technology is built into the Raymarine A50D and A57D (A70D is now end of line although limited stocks may still be found through some Raymarine dealers) models and all models are available with or without pre-loaded Navionics charts.








Raymarine Multifunction Display Comparison



  e9 c12
A Series
C Series Widescreen
E Series Widescreen
G Series monitors
Model New e Series  New c Series



A Series





C Series Widescreen





E Series Widescreen





G Series





 Display
Display sizes

7, 9 and 12 in

(178, 229 and 307mm)


9 and 12 in

(229 and 307 mm)

5, 5.7 and 6.4 in
(127, 144 and 162 mm)

9, 12 and 14 in
(229, 307 and 358 mm)

9, 12 and 14 in
(229, 307 and 358 mm)
12, 15, 17 and 19 in

(307, 380, 430 and 480 mm)

Color LCD display
Large bullet
Large bullet
Large bullet
Large bullet
 Large bullet
 Large bullet
Touchscreen operation Large bullet
Large bullet

Customizable screens Large bullet Large bullet
 Large bullet
 Large bullet
Large bullet
Large bullet
 Chartplotter
Preloaded Navionics -

ready to navigate

charts

 Large bullet  Large bullet Large bullet  Large bullet  Large bullet Large bullet
Macro region Navionics

Platinum cartography

pre-installed

          Large bullet
GPS built in sensor Large bullet  Large bullet Large bullet  Large bullet
 Radar
HD and Super HD Color

Radar compatible

Large bullet  Large bullet   Large bullet  Large bullet Large bullet
Bird mode* Large bullet Large bullet     Large bullet Large bullet
48rpm*  Large bullet Large bullet     Large bullet Large bullet
 Fishfinder
Built in HD Digital Sounder Large bullet  Large bullet  Large bullet
DSM30 and DSM300

HD Digital Fishfinder capability

 Large bullet  Large bullet   Large bullet Large bullet  Large bullet
DSM400 High Power

HD Digital Fishfinder capability

      Large bullet  Large bullet  Large bullet
CP450C CHIRP Sonar capability Large bullet Large bullet
 Other features
Ultrabright display  Large bullet Large bullet       Large bullet  Large bullet
Widescreen display  Large bullet Large bullet    Large bullet   Large bullet
Support for AIS target tracking  Large bullet Large bullet  Large bullet  Large bullet Large bullet Large bullet
Display video Large bullet Large bullet   Large bullet Large bullet  Large bullet
Integration with

SeaTalk instruments

and autopilots



Converter required

 † Large bullet Large bullet Large bullet



Raymarine SeaTalkhs Connections

SeaTalkHS diagram with HS5

SeaTalkhs Plug and Play



By using SeaTalkhs networking, you can instantly transfer radar, chartplotter, fishfinder, thermal imaging and navigation functions. Configuring your system is a simple as determining which SeaTalkhs devices you'd like to have (chart, radar, sonar, video) and where you would like to see them.



space



Networking two devices



The most basic system may consist of a C Series Widescreen or an E Series Widescreen with a DSM30, DSM300 or a radar.



Using a SeaTalkhs Crossover coupler, they can be quickly and easily connected together. Because the components are all auto sensing, there is no complicated setup required. Simply plug them in.



If you're not using a DSM, you can link any two E Series Widescreen displays with the crossover coupler too.

 Sea Talk HS with coupler and E Series Wide





space





HS-5 SeaTalk HS Network Switch

Multistation Networking - New HS-5 SeaTalkhs Network Switch



SeaTalkhs data is quickly distributed to other SeaTalkhs using the HS-5 Network Switch.



The switch has 5 ports - 4 RayNet ports supporting 10 or 100 Mbit/sec network speeds and a 5th gigabit port allowing a higher speed across switches, should a 2nd switch be necessary.









When networking three to eight SeaTalkhs devices, the SeaTalkhs Network Switch can be used.





The auto sensing SeaTalkhs components make setup a breeze, simply plug them in. SeaTalkhs does the rest.

SeaTalk HS Network Switch





space



SeaTalkhs Raymarine Products



The following devices have SeaTalkhs connections and can be easily connected together via the SeaTalkhs network switch and SeaTalkhs network cables:





E Series SeaTalk HS network





space





 SeaTalk HS Cable

SeaTalkhs Network Cables



Available in multiple lengths to simplify installation, the SeaTalkhs network cable locks positively into switches and couplers.





Sizes Available Product Number
1.5m E55049
5m E55050
10m E55051
15m A62135
20m E55052













space





SeaTalkhs Patch Cables



Highspeed patch cable for connecting a SeaTalkhs switch with a PC or G Series monitor.





Sizes Available Product Number
1.5m E06054
5m E06055
10m E06056



Patch cables





space





Raymarine Multifunction Displays


aSeries

5.7" and 7" plus 9" and 12" touchscreen network displays with fluid, tablet like all touch screen user interface.

EXPLORE

cSeries

9" and 12.1" keypad controlled network displays with widescreen LCD formats and LED backlighting.

EXPLORE

eSeries

7" to 15.4" high performance network displays with HybridTouch™

EXPLORE



NEW eS Series

Whether you fish, sail, or just cruise the open water, eS Series’ advanced LightHouse II operating system with HybridTouch™ gives you total control.

EXPLORE

gS Series

9" to 19" Glass Bridge touchscreen network displays. Elegant, flexible and simple to use.




EXPLORE

LightHouse II Software

The easy to use operating system inside every Raymarine multifunction display. Learn what's new and upgrade today.

EXPLORE






Accessories for Multifunction Displays



Marine Charts

Choose from three cartography options - Raymarine's LightHouse Charts, Navionics or C-MAP by Jeppesen

EXPLORE

AIS

Enable the wireless exchange of navigation status between vessels and shore-side traffic monitoring centres.

EXPLORE

Digital Switching

Control onboard electrical and electronic systems like lighting, air-conditioning, navigation lights and much more.

EXPLORE

Engine Interfacing

Bridge engine instrumentation and drive-by-wire steering with Raymarine autopilot and navigation systems

EXPLORE



Marine Weather

Stay ahead of the front with SIRIUSXM Marine Weather (Available in th USA only)




EXPLORE

Networking

Everything you need to know about the most popular networking systems, including SeaTalk, RayNet and more

EXPLORE

GPS Sensor

Choose your display option to find out if you need an external GPS and how to connect a RS130 to your system

EXPLORE

Transducer

The type of transducer required depends on the multifunction display you're using, your vessel (type of hull) and the performance you require.

EXPLORE





space



space








Raymarine Comparison



牋牋


__________________________________________________________________________________________


**The price is subject to change at anytime without any notice.  We are not responsible for any typographical errors.  Any products can be cancelled from sale at any time.

** All Products sold here are Brand New unless specified Otherwise and come with Full Manufacturer's Warranty



WarningWARNING: This product can expose you to chemicals including Di-n-hexyl Phthalate (DnHP) which is known to the State of California to cause reproductive harm, and Vinyl Chloride which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. __________________________________________________________________________________________



__________________________________________________________________________________________

Please contact us via email ask@wmjmarine.com or Call us at


__________________________________________________________________________________________




Customer Rating


Top Rated

We offer online shipment tracking



VeriSign Trust Seal
256-bit Encryption Shopping Cart

All personal information submitted is encrypted and 100% secure

__________________________________________________________________________________________


Garmin
Products
Garmin Autopilot
Garmin GPS Chartplotter
Garmin Fishfinder
Garmin Radar

Garmin Trolling Motor
Automatic Identification System


Raymarine
Authorized Reseller
Raymarine Autopilot
Raymarine GPS Chartplotter
Raymarine Fishfinder
Raymarine Radar

Automatic Identification System

Simrad
Authorized Reseller
Simrad Autopilot
Simrad GPS Chartplotter
Simrad Fishfinder
Simrad Radar

Automatic Identification System

Lowrance
Authorized Reseller
Lowrance Autopilot
Lowrance GPS Chartplotter
Lowrance Fishfinder
Lowrance Radar
Lowrance Trolling Motor

Furuno
Authorized Reseller


Furuno Autopilot
Furuno GPS Chartplotter
Furuno Fishfinder
Furuno Radar

Automatic Identification System

Humminbird
Authorized Reseller
Humminbird GPS Chartplotter
Humminbird Fishfinder
KVH
Authorized Reseller
Marine Satellite TV
Marine Internet
JRC
JRC GPS
JRC Fishfinder
JRC Radar
ACR
Search Light
EPIRB
Personal Beacon
GMDSS VHF Radio


Cannon
Downrigger
Comnav
Marine Autopilot
Satellite Compass
Fusion
Marine Stereo
Authorized Reseller

Icom
Mounted VHF Radio
Handheld VHF Radio
Intellian
Marine Satellite TV
Marine Internet
Lewmar
Windlass
Bow Thruster
Sail Winches


Maxwell
Windlass
Minn kota
Trolling Motors
Motorguide
Trolling Motors
Revere
Liferaft

Authorized Reseller

Viking
Liferaft

Authorized Reseller
Seaview
Radar Mount
Xantrex
Battery Charger
Inverter Charger
Inverter
B&G
Authorized Reseller
B&G utopilot
B&G PS Chartplotter
B&G Instrument



Blue Sea System
Distribution Panel
Battery Charger

Seastar Teleflex
Boat Steering
Engine Control
Power Assist
Velair
Marine Air Conditioning

Navionics
Marine Chart

Si-Tex
Sitex Autopilot
Sitex GPS Chartplotter
Sitex Fishfinder

Sitex Radar


FLIR
Thermal Camera

Authorized Reseller
Mastervolt
Battery Charger
Inverter Charger
Inverter

OceanLED
Underwater Light

Lumishore
Underwater Light



Uflex
Steering & Engine Control

Lumitec
Underwater Light

International Dock
power pedestal

ProMariner
Battery Charger
Inverter Charger
Inverter

Newmar
Battery Charger
Inverter Charger
Inverter
DC Converter
DC Power Supply



Jabsco
Water Pump
Marine Toilet
Magnum
Authorized Reseller
Battery Charger
Inverter Charger
Inverter
Raritan
Water Heater
Waste Treatment


Rupp
Outriggers
Taco
Outriggers


Lee's
Outriggers
Actisense
NMEA Networking
Max Power
Bow Thruster
Stern Thruster
Mustang

Life Vest
Dry Suit
Work Suit
Immersion Suit

McMurdo

EPIRB
SART
Personal Beacon

Airmar

Sonar Transducer
Weather Station

Victron

Marine Isolation Transformer
Marine Battery Charger
Inverter Charger

Dometic

Marine Air Conditioning

__________________________________________________________________________________________


Recommended Site: WMJ Marine at Facebook   |  WMJ Marine at Linkedin  |  WMJ Marine at Twitter | Marine Electronics Store

Thank you for visiting WMJ marine for your Boating Equipment and Marine Electronics

Home | Anchor & Docking | Autopilot | Boating Accessories | Cabin/ Galley/ Deck | Communication | Electrical Supply | Electronics | Engine Parts | Fish Finder | Fishing & Sailing | GPS & Chartplotter | Instrument | Lighting | Marine Radar | Navigation Tool | Outdoor Gears | Plumbing & Pump | Safety | Steering & Control | Trolling Motor | Factory Refurbished | Specials of the Month | Rebate of the Month | New Products
Our Company Policy | Privacy Policy | Shopping Cart

Marine Supply Specialist, USA - WMJ Marine Corporation

Copy Right: WMJ Marine Corporation 2004-2024
