Extreme-Duty Confidence for Marine & Autonomous Systems
When equipment lives offshore, on deck, or in dusty environments, exposure is
constant and failure is expensive.
The 300WX-IP67 delivers the same
next-generation intelligence as the 300WX, but in a fully sealed, IP67-rated
housing engineered for continuous exposure to water, dust, vibration, and harsh
marine conditions.
This is the model trusted for offshore platforms, buoys, unmanned surface
vehicles, commercial workboats, and long-duration autonomous deployments.
It’s designed not just to perform — but to endure.
True Wind. True Awareness. Even at Sea.
On moving vessels, apparent wind alone is misleading. The 300WX-IP67
continuously calculates Dynamic True wind by integrating GNSS speed data with
stabilized heading and motion data to cancel out apparent wind and deliver the
True wind speed and direction. That clarity improves navigation decisions,
supports autonomous control systems, and enhances vessel performance
optimization.
Built for Harsh Reality
The IP67 enclosure protects against water and dust intrusion, while the proven,
rugged housing durability enhances long-term reliability in exposed
environments. The 300WX-IP67 removes worry from the equation. It simply
continues working — through spray, salt, vibration, and long deployments.
Seamless Connectivity Without Complexity
Like its counterpart, the IP67 model integrates easily into marine and
industrial networks, including NMEA 2000®, NMEA 0183, J1939, and ISOBUS systems.
Bluetooth** connectivity with Airmar's CAST™ enables remote configuration and
firmware updates without removing it from its installed location — especially
valuable for mast-mounted or difficult-to-access installations.
**Non-Bluetooth models are available upon request. Visit our How-to-Buy page
to make contact with our sales offices.
Brand: Airmar
Technology
Air Temp Accuracy: ±1.1°C
at 20°C
Air Temp Range: -40
to 80°C (-40 to 176°F)
Air Temp Resolution: 0.1°C
Barometric Pressure Accuracy: ±1
hPa at 25°C
Barometric Pressure Range: 300
to 1100 hPa
Barometric Pressure Resolution: 0.1
hPa
Certs And Standards: CE,
RoHS, IEC61000-4-2, IEC60945, IEC60950_1C, IEC60950_22A, EN55022, EN55024,
EN14982; Ingress Protection, IP66 (IP64 with optional Relative Humidity
sensor)
Communications Available Hardware Interface: Serial
RS232, Serial RS422, CAN
Communications Available Protocol: Serial
- NMEA 0183, CAN NMEA 2000, J1939, ISOBUS
Communications Serial Data Transmission Code: ASCII
Communications Serial Output Rate: 1
Hz typical. User selectable. 10 Hz maximum recommended
GNSS Position Accuracy: 2.5
m (8’) CEP ‡
Note: Cables
sold separately unless otherwise specified
Operating Temp Range: -25
to 55°C (-13 to 131°F)
Pitch Roll Accuracy: ±1°
in range of ±30°
Pitch Roll Measurement Type: MEMS
Pitch Roll Range: 50°
Power Supply Current: <75
mA (<0.9 W) at 12 VDC
Power Supply Voltage: 9
to 40 VDC
Recommended Use: Marine
Mobile or Stationary
Three Axis Compass Dynamic Heading Accuracy: 2°
dynamic heading accuracy
Three Axis Compass Range: 0
to 359.9°
Three Axis Compass Static Heading Accuracy: 1°
static heading accuracy
Weight: 300
g (0.7 lb.)
Wind Direction Accuracy: 2.5°
RMS @ 20 knots
Wind Direction Range: 0°
to 359.9°
Wind Direction Resolution: 0.1°
Wind Speed Accuracy: 1.5
knots RMS @ 20 knots
Wind Speed Calculations: User
configurable damping
Wind Speed Range: 0
to 40 m/s (0 to 89 MPH)
Wind Speed Resolution: 0.1
m/s
Exterior Color: White
Humidity: Optional,
Not Available
Waterproof Rating: IP67,
IP64
NMEA 2000 LEN: 2
Mounting Thread: Standard
1”-14 UNS (3/4” NPT optional)
Sensor Connector: 10WS
Display Connector: Cable
Required
Exterior Color: White
Refurbished: No
Comm Method: NMEA
2000®
Country of Origin: USA
RoHS Compliant: Yes
